Single acting Hydraulic Cylinder for Crop Protection Equipment

Our products are widely used in municipal sanitation, domestic waste treatment, special-purpose vehicles, rubber and plastics, metallurgy, military industry, marine engineering, agricultural machinery, textiles, electric power chemicals, engineering machinery, forging machinery, casting machinery, machine tools and other industries.

  • Description
  • Single Acting Hydraulic Cylinders for Crop Protection Equipment refer to a series of single acting hydraulic cylinders installed mainly on agricultural implements that are used to protect crop and other plants, such as flail mower, tractor operated sprayer, fodder harvester, etc.These cylinders feature a single port at one end of the cylinder, through which the hydraulic fluid is pumped to displace the rod and cause it to extend in one direction only.

    Main features of the hydraulic cylinders for crop protection machine are as followings:

    √ Wide range of outside working temperature,lowest working temperature down to -40℃.

    √ Energy-efficient, short operation time with long resting period.

    √ Small working load, the cylinders are mainly used for requested movements.

    To fulfill these features, our hydraulic cylinders for plant protection machines are produced in a special technical process with advanced sealing techniques to ensure that the cylinders are low-temperature-resistant, abrasion-proofing and anti-corrosion.

    We had have the ability to produce the hydraulic cylinders for plant protection by a special technical process of low temperature resistance, low friction and low pressure.



    Product Specification

    Name

    Quantity

    Bore Diameter

    Rod Diameter

    Stroke

    Ladder Lifting hydraulic cylinder

    2

    40

    20

    314

    Pesticide Frame Expansion hydraulic cylinder 2

    2

    40

    20

    310

    Cover lifting hydraulic cylinder

    1

    50

    25

    150

    Slasher frame folding hydraulic cylinder

    2

    50

    35

    225

    Slasher frame lifting hydraulic cylinder

    6

    60

    35

    280

    Pesticide Frame Expansion hydraulic cylinder 1

    2

    50

    35

    567

    Steering hydraulic cylinder with sensor

    2

    63

    32

    215

    Steering hydraulic cylinder

    2

    63

    32

    215

    Tire stretching hydraulic cylinder

    4

    63

    35

    455

    Pesticide frame rotary hydraulic cylinder

    2

    63

    35

    525

    Pesticide frame lifting hydraulic cylinder

    2

    63

    40

    460

    Pesticide frame lifting hydraulic cylinder

    2

    75

    35

    286



    Competitive Advantages

    √ High Qualities: Cylinder body and piston are made from solid chrome steel and heat-treated.

    √ Great Durability: Hard-chromium plated piston with replaceable, heat treated saddle.

    √ Stronger Mechanical Strength: Stop ring can bear full capacity (pressure) and is fitted with dirt wiper.

    √ Corrosion Resistant: Perfectly passed the neutral salt spray test (NSS)Grade 9/96 hours.

    √ Long life span: FAST cylinders have passed over 200,000 cycles cylinder life test.

    √ Cleanliness:Through fine cleaning, surface detection, ultrasonic cleaning and dust-free transfer during the process, and laboratory test and real-time cleanliness detection after assembly, FAST cylinders have reached Grade 8 of NAS1638.

    √ Strict Quality control: PPM lower than 1000.



    Considerate Services

    √ Sample Service:Samples will be provided according to customer's instruction.

    √ Customized Services:A variety of cylinders can be customized according to customer demand.

    √ Warranty Service: In case of quality problems under 1 year warranty period, free replacement will be made for customer.





    Company Profile

    Establish Year

    1973

    Factories

    3 factories

    Staff

    500 employees including 60 engineers,30 QC staff

    Production Line

    13 lines

    Yearly Production Capability

    Hydraulic Cylinders 450,000 sets;

    Hydraulic System 2000 sets.

    Sales Amount

    USD45 Million

    Main Export Countries

    America,Sweden,Russian,Australia

    Quality System

    ISO9001

    Patents

    89 patents

    Guarantee

    13 months
